MAS 40

Mini array spectroradiometer

MAS 40

MAS 40

Mini array spectroradiometer

MAS 40 – High-quality, robust CCD spectrometer technology

The compact, low cost MAS 40 mini-array spectrometer has a wide range of uses in industrial quality control as well as in research and development. It satisfies all Instrument Systems guaranteed quality requirements for spectroradiometers for the absolute measurement of light radiation. This includes calibration with the desired measurement adapter that is traceable to national and international standardization bodies such as PTB or NIST.

The MAS 40 is compatible with the complete set of Instrument Systems accessories via an optical fiber. This opens up a broad range of applications in photometry. Since the power supply is connected via USB, the MAS 40 is ideal for mobile use on the laptop.


Key Features


• Robust CCD spectrometer technology
• All measurement adapters from Instrument Systems can be connected
• Different models for the spectral ranges UV-VIS and VIS-NIR
• Simple operation using SpecWin Pro/Light software
• DLL and LabVIEW® drivers for integration in customer applications
• Standard USB interface
• Extremely compact design (145 x 90 x 185 mm)
• Density filter available to extend measurable intensity range



Technical data and specifications


Model variants

UV/VIS

VIS/NIR

Spectral range

250-830 nm

380-950 nm

Spectral resolution

2.7 nm

2.7 nm

Data point interval

0.33 nm

0.33 nm

Stray light for LED

5·10-4

5·10-4

Wavelength measurement accuracy

±0.5 nm

±0.5
