Accessories DMS

Complete portfolio for the characterization of displays and components

Accessories DMS

Accessories DMS

Complete portfolio for the characterization of displays and components

Measurement setup – maximum test capabilities!

Instrument Systems has developed a comprehensive range of accessories for its DMS systems. These include precise and fast light meters, temperature control chambers and light sources, together with positioning and control units. It represents a complete display measuring system for the full electro-optical characterization of displays in one setup.


Light sources and lighting units

  • DHS diffusing hemisphere
  • SDR integrating sphere for diffuse reflectance
  • VADIS variable aperture diffuse source
  • PID parallel illumination device
  • PLS point light source

Unit for sample control

Every DMS system incorporates an efficient interface as a DUT control unit. This is required for the measurement of optical parameters subject to the electro-optical operating states of the display or for conducting automatic display tests.

Components, measuring instruments or test objects with a variety of mounts and interfaces can be connected and controlled via the interface. It is compatible with analog signals, RJ45 Ethernet, RS232, USB, a 230 V power supply and SUBMIN D9 connectors. Standard signals such as HDMI or DVI can also be realized for LCD and display modules.



Examples of applications
