Calibration LEDs

Stable audit light sources of the ACS series

Calibration LEDs

Calibration LEDs

Stable audit light sources of the ACS series

LED-based standards with high stability for the verification of your measurement systems

Regular testing of your measuring instruments with calibration standards is the basis for all quality assessments in light measurement technology!

As market leader in LED measurement technology, Instrument Systems offers standards on an LED basis for a wide range of applications:

Calibration standards Series ACS 570

Designed for photometric quantities luminous intensity, averaged LED intensity (ILED-B) and luminous flux. For applications in the UV and IR range specified for the radiometric quantities irradiance and radiant power.

Calibration standards Series ACS 585 and ACS 150

Suitable for measuring luminance. Due to the specified two-dimensional uniformity, model ACS 150 offers the option of verifying the sensor calibration of imaging colorimeters.

Calibration standards Series ACS 590

Developed for examining the luminous intensity of optical probes. IR models are suitable for testing irradiation intensity with various peak wavelengths in the IR range.

All photometric calibration LEDs can additionally be used to check the color coordinates x and y.

Simple and reliable verification of measurement equipment from Instrument Systems is possible with the ACS series of standards. Furthermore, the absolute photometric value of the standard can be used to correct or recalibrate the absolute calibration of a measuring instrument as needed.


Audits – the basis for all quality evaluations in light measurement applications

Only regular checks of a measuring system for conformity with its specifications will ensure the proper functioning and quality of the measuring system and the comparability of readings in the long term. For this purpose, the audit portfolio from Instrument Systems offers a large selection of application-specific solutions.



Key Features

Temperature-stabilized, cooled high-power LED
High photometric and radiometric stability
Reference values traceable to national standards with an indication of measurement uncertainty
Highest operational safety when used with control unit PSU 10
All-in-one solution with power source, temperature stabilization and software



Technical data and specifications


Model

ACS 150

ACS 570

ACS 585

ACS 590

Photometric quantity (incl. color coordinates)

Luminance

Luminous flux / intensity

Luminance

Illuminance

Radiometric quantity

-/-

Radiant power / intensity

-/-

Irradiance

Lateral uniformity

Specified

-/-

-/-

-/-

LED

Cold white

Cold white/ R / G / B / IR

Cold white

Cold white / IR

Dimensions [mm³]

262x181x153

110x77x54

205x105x120

177x120x151
